JF-0530B DC Push-Pull Solenoid 6V 12V 24V Linear Electromagnet 5N
JF-0530B DC Push-Pull Solenoid 6V 12V 24V Linear Electromagnet 5N
JF-0530B DC Push-Pull Linear Solenoid Electromagnet
The JF-0530B DC Push-Pull Solenoid is a compact, reliable linear electromagnet designed for a wide range of automation and mechanical applications. Available in 6V, 12V, and 24V configurations, this push-pull electromagnet delivers a consistent 5N force over a 10mm stroke, making it ideal for vending machines, transportation equipment, office automation, home appliances, and industrial machinery.
Made in Mainland China.
Key Features
- Multi-Voltage Compatibility: Available in DC 6V (750mA), DC 12V (300mA), and DC 24V (300mA) — choose the voltage that suits your application.
- Push-Pull Linear Motion: Operates via piston return mechanism — when energised, the solenoid pulls the push rod to perform the desired linear action.
- Compact & Lightweight: Body dimensions of only 30 × 16 × 15mm make it easy to integrate into tight spaces.
- Low Power Consumption: Efficient design minimises energy use without sacrificing performance.
- Long Service Life: High-quality metal and electronic component construction for durability and reliability.
- Easy to Install: 2.5mm mounting hole diameter and 20cm pre-attached cable for fast, hassle-free setup.
Technical Specifications
| Model | JF-0530B |
| Type | DC Push-Pull Electromagnet |
| Rated Voltage | DC 6V / 12V / 24V (optional) |
| Rated Current | 750mA (6V) / 300mA (12V) / 300mA (24V) |
| Force & Stroke | 5N / 10mm |
| Body Dimensions | 30 × 16 × 15mm |
| Piston Bar Dimensions | 6 × 58mm |
| Mounting Hole Diameter | 2.5mm |
| Cable Length | 20cm |
| Material | Metal, Electronic Components |
| Condition | New |
Common Applications
- Vending machines & dispensing systems
- Transportation & sorting equipment
- Office automation equipment
- Home appliances with actuator mechanisms
- Industrial machinery & automation projects
- DIY electronics & robotics projects
Package Contents
- 1 × JF-0530B DC Push-Pull Solenoid Electromagnet
