Diymore 3W+3W Dual-Channel Bluetooth Speaker DIY Soldering Kit
Diymore 3W+3W Dual-Channel Bluetooth Speaker DIY Soldering Kit
Build Your Own Bluetooth Speaker – The Ultimate DIY Soldering Kit
The Diymore 3W+3W Dual-Channel Bluetooth Speaker DIY Kit is the perfect hands-on electronics project for students, hobbyists, and makers. Assemble a fully functional stereo Bluetooth speaker from scratch while developing real-world soldering skills. With a crystal-clear acrylic housing, rhythm-synced LED lights, and impressive audio output, this kit blends education with entertainment. Made in Mainland China.
Key Features
- 3W + 3W Dual-Channel Stereo Output – Delivers clear, balanced sound from two full-range 4Ω speakers with PU surround and 40mm magnets.
- Bluetooth Connectivity – Pair via mobile Bluetooth (device name: XC046) for wireless audio streaming from any smartphone or tablet.
- USB Drive Playback – Automatically switches to USB flash drive mode when Bluetooth disconnects, keeping the music going.
- Power-Off Memory Function – Remembers your last playback settings so you pick up right where you left off.
- Remote Control Included – Power on/off and adjust volume without touching the unit.
- Sound-Activated LED Lights – LEDs flash and flow in sync with audio rhythm and volume for a vivid visual experience.
- Crystal-Clear Acrylic Housing – Six panels of 3mm high-transparency acrylic snap together for a sleek, showcase-worthy finish. (Remove the brown protective film before assembly.)
- Ideal for Learning – Designed specifically for soldering practice and DIY educational training, making it a great classroom or workshop project.
Technical Specifications
| Channel Output | 2-Channel Stereo |
| Output Power | 3W + 3W |
| Supply Voltage | DC 4.2–5V (5V max — do not exceed) |
| Rated Current | 1.5A – 2A |
| Speaker Impedance | 4Ω |
| Speaker Size | 40mm magnet, full-range with PU surround |
| Power Input | USB (5V phone charger or computer USB port) |
| Condition | New (self-assembly required) |
How It Works – Circuit Overview
The Bluetooth module's red terminal supplies 5V power, while the white terminal connects to the left and right speaker channels. Red wire = positive (+); black wire = negative (−). The sound-activated LED circuit consists of a power supply circuit, microphone amplification circuit, and LED indicator circuit. The microphone captures audio signals, amplifies them through transistor Q1, and drives the LEDs — louder sounds produce brighter, faster-flowing light patterns for a stunning audio-visual display.
Wiring Quick Reference
- White terminal → Speaker connection
- Red terminal → Power supply connection
- Bluetooth pairing: Enable Bluetooth on your device → Scan → Select XC046 → Connect
- For best audio quality, use a 5V 2A power supply
What's in the Box
- DIY component set × 1 (includes pre-soldered Bluetooth circuit boards, USB power cable, acrylic panels, speakers, and all electronic components)
⚠️ Important Note: All components require self-assembly. Follow the included instructions carefully — incorrect wiring may result in malfunction. Do not exceed 5V supply voltage.
